Product Overview



The equipment can make the powder material into the required mesh particles, Increasing the specific gravity and fluidity of the material; through the double screw rod horizontal feeding mode, pressure roller cooling and vacuum exhaust system, effectively reduce the content of fines in the finished product, improve the quality of the drug compression, and good preparation of material is provided for the subsequent tablet and capsule filling.the equipment has a very strong applicability to a variety of materials, the granulation process does not apply to any additives, and the required mesh number of particles can be made according to different needs. has a simple process, production batch size, easy to clean and maintain and other characteristics.



Equipment Functions



◆ Built-in stirrer in the feeding device prevents large materials from blocking the pushing channel and ensures uniform feeding.

◆ Vacuum exhaust system reduces the proportion of air in the material and increases its compactness.

◆The material is fed by double screw rods, forcing pre-pressurization of the material, and the rotating speed is continuously adjustable.

◆ Vertical arrangement of pressure roller adopts special stainless steel, and its surface hardness reaches >HRC45 after special treatment.

◆Different surface shapes can be adopted according to different material characteristics.

◆ The main drive adopts adjustable hydraulic support to ensure stable pressure and even density in the pressing process.

◆ The press roll is cooled by external circulating water cooler to adapt to the pressing of temperature-sensitive materials.

◆ Equipped with main drive, pressure overload, roller chamber opening and other closing protection devices.

◆ Integral mask, easy to operate.

◆ Pressure roller chamber is completely sealed and its working condition is observed through transparent tempered glass.

◆ One-level D-type large whole grain structure improves the grain yield.

◆ The screen mesh can be replaced as needed to get different mesh number of material granules.

◆ The parts contacting with materials are made of stainless steel or polymer materials.

◆ The speed ratio between feeding screw and pressure roller can be changed to get granules of different hardness (or specific gravity).

◆Reducer are adopted SEW famous brand products.

◆Select Siemens PLC+color touch screen, Chinese interface, with automatic display and fault alarm function.

◆ It has the functions of setting machine parameters and working mode, setting password and storing operation records.
