Mobile Mill

By high-speed movement between the rotator and sieve, block materials will be agitated and extruded, and particles will be formed immediately through sieve hole. It usually cooperates with wet granulators and fluid bed dryers. It is easy to disassemble and clean, meeting GMP standard.

Frequency control and spindle speed can be adjusted in a wide range.

Bottom drive for smooth feeding.

High-quality stainless steel is used for the parts in contact with materials and the exterior parts.

It is exquisite, easy to disassemble and clean with flexible installation modes.





Details



Specification

Mobile Mill

Model Capacity Mesh Size
Unit kg/h mm
  Both wet and dry mill Square Round
YZLJ-125 <250 3*3-10*10 Φ0.5-Φ5.0
YZLJ-150 200-500 3*3-10*10 Φ0.5-Φ5.0
YZLJ-200 500-1500 3*3-12*12 Φ0.5-Φ5.0
YZLJ-250 1500-2500 3*3-14*14 Φ0.5-Φ5.0
YZLJ-250+ 1500-3000 3*3-14*14 Φ0.5-Φ5.0



* All of the above are standard configuration, and can be customized if there are special requirements.

* All rights for changes reserved.
