GHL(Z) High Shear Mixer / Wet Granulator

It works by using the intense agitation to make the materials do axial, radial and tangential movement, resulting in uniform mixing. Then, the materials will be cut into spherical particles by high-speed chopper.

The high shear mixer granulator adopts the traditional horizontal cylinder and cone structure, which has high tumbling efficiency and good material uniformity. The strong competitiveness of our wet granulator lies in higher production efficiency, higher yield, easy operation, better reproducibility and better uniformity. The produced particles have good uniformity, less fine powder and good fluidity.

Better scale-up, real-time, realistic and sensitive key process parameters

The bottom and wall of the container are materials free, and the spherical outlet can make all the materials discharge completely

The process endpoint can be controlled by torque It can be applied to the experimentation and production of DPI products

Good performance of mechanical seal and hermetic seal At a mixing ratio of 1:0.00078, the RSD can reach below 0.5%.

The cooling layer design is suitable for granulation with temperature control

The heating layer design is suitable for melt granulation

Multi-function: it can complete the dry-blending, wet blending and granulation, complied with cGMP, shortening the production time.

Application Field

The application fields include tablets, capsules, granules, fine particles, inhalants, etc. For example, it can be used for herbal granules, chemical medicine granules, dry powder mixing, etc.

chemical medicine granules

chemical medicine granules

herbal granules

Specification

GHL(Z) High Shear Mixer / Wet Granulator

Model GHL-30 GHL-50 GHL-100 GHL-150 GHL-200 GHL-300
Working volume(L) 7-22 13-40 27-83 44-132 52-158 86-259
Model GHL-400 GHL-600 GHL-800 GHL-1000 GHL-1200 GHL-1600
Working volume(L) 102-308 155-465 200-602 251-754 324-972 417-1253



* All of the above are standard configuration, and can be customized if there are special requirements.

* All rights for changes reserved.
